Inspect all o-rings for cuts, tears or nicks. The rebound assembly, the Pure tube and the compression assembly make up the Pure system (right side of the fork). Remove both shaft bolts (or shaft bolt and air nut) completely PURE SYSTEM SERVICE GUIDEĦ PURE SYSTEM SERVICE GUIDE O-ring to Inspect Seal Head Rebound Assembly Pure Tube 13 Compression Assembly O-rings to inspect 13. This releases the pressure fit between the lower legs and the shafts. This will make it easier for steps where you must cycle the rebound shaft Using a dead blow mallet, tap the shaft bolts. Note: Fully open the rebound adjuster (counterclockwise rotation). For SID SL and Psylo Race: Use a 5mm hex wrench to unscrew the right shaft bolt four turns and a 10 mm socket to unscrew the air nut on the left side four turns. For Psylo SL: Use a 5mm hex wrench to unscrew both shaft bolts four turns. Remove the rebound adjuster knob from the right shaft bolt. NOTE: A SMALL AMOUNT OF OIL MAY COME OUT WHEN RELEASING THE AIR 2. Depress the schrader air valve to remove the positive air pressure. Remove the positive air valve cover from the top of the left upper tube. Depress the schrader air valve to remove the negative air pressure b. Remove the negative air valve cover from the bottom left lower leg.
For SID SL and Psylo Race: Remove the air pressure from the fork. oil REMOVING THE LOWER LEGS 2 HINT: RIGHT AND LEFT SIDE IS DETERMINED AS IF YOU WERE ON THE BIKE 1.
2 PURE SYSTEM SERVICE GUIDE TOOLS NEEDED Safety Glasses 2 and 5 mm Hex Wrench 10 mm Hex Socket (for SID SL and Psylo Race) Plastic Faced Mallet 24 mm Socket and Ratchet Snap Ring Pliers Dental Pick or Magnetic Screw Driver 50 cc Syringe (may be purchased at a motorcycle shop or medical supply store) Oil Pan Judy Butter 5 wt.
